Liquid Differential Pressure Sensor 0/10Vdc
£340.00 Exc. VAT
The 482 range of Liquid DP sensors use a piezo-resistive sensor and incorporate zero and span adjustment.
They are ideal for use in areas requiring exact pressure measurement, low hysteresis and long-term stability in all applications where air, oil or water is to be monitored.
Description
The 482 range of Liquid DP sensors use a piezo-resistive sensor and incorporate zero and span adjustment.
They are ideal for use in areas requiring exact pressure measurement, low hysteresis and long-term stability in all applications where air, oil or water is to be monitored.
Specification
Output Signal: 0…10Vdc 3 wire
Power Supply: 24Vac/dc
Pressure Ranges: Select Range
Over Pressure: 1.5 x FS
Accuracy: 0.25% FS
Repeatability: 0.2% FS/Year typical
Pressure Connection: ⅛” BSP female
Temperature: -20…+80˚C
Humidity: 0…80% RH
Business & Industrial > Automation Control Components
| Weight | 0.39 kg |
|---|---|
| Dimensions | 16 × 11 × 6 cm |
| Pressure | 0-0.4 Bar, 0-1 Bar, 0-2 Bar, 0-4 Bar, 0-7 Bar, 0-10 Bar |
