Wind Speed Sensor – AV-WSS
£650.00 Exc. VAT
The AV-WSS wind speed sensor provides wind speed measurements and converts those measurements into a pulsed output which can be read by a PLC or Building Management System.
Description
The AV-WSS wind speed sensor provides wind speed measurements and converts those measurements into a pulsed output which can be read by a PLC or Building Management System.
Specification
Electrical Conn:Â Â Â Â Â Â Â Â Flying lead 3m long.
Ambient Temperature:Â Â Â -20ËšC/+70ËšC
Dimensions:Â Â Â Â Â Â Â Â Â Â Â Height 280mm.
Protection:Â Â Â Â Â Â Â Â Â Â Â Â IP65
Wind Speed Output:Â Â Â Â Â 1 contact closure per 1.493m/s (zero bounce).
Min. Start Speed:Â Â Â Â Â Â Â Â Â Â Â Â 0.5m/s
Accuracy:             ± 2%
Contact Rating:Â Â Â Â Â Â Â Â Â 50W, 100Vdc max, 1A
Direction Output:        0-1KΩ for 0-357˚
Mechanical Travel:Â Â Â Â Â 360Ëš endless travel.
Electrical Travel:       357˚ (± 2˚)
Resistance Tolerance:  ± 3%
Linearity Tolerance:     ± 0.5%
| Weight | 1.3 kg |
|---|---|
| Length | 80mm, 140mm, 195mm, 250mm |
