Water Detection Module WL-DT24
Price range: £30.00 through £33.00 Exc. VAT
The WL-DT24-D has been designed as a low-cost water detection module suitable for use as a level alarm for water tanks or drip trays. It has 1 normally open contact and can be supplied as a panel mount or Din Rail mount.
Description
The WL-DT24 has been designed as a low-cost water detection module suitable for use as a level alarm for water tanks or drip trays.
It has 1 Normally open contact and can be supplied as a panel mount or Din Rail mount.
Specification
Output: 10Amp @ 230Vac Normally open contact
Supply Voltage: 24Vac/dc +/- 10% 25mA max.
Termination: Rising clamp for 0.5 to 2.5mm² cable
Ambient: -10 to +40°C
Dimensions: Din rail mount: 58(W) x 50(D) x 92(H)mm
WL-DT24 24Volt Water Detection Module (Panel Mount)
WL-DT24/D 24Volt Water Detection Module (Rail Mount)
LED Status:
Steady green– Standby
Short Pulse– Short circuit sensor.
Quick flashing– water detected.
| Weight | 0.7 kg |
|---|---|
| Dimensions | 5.8 × 5 × 9.2 cm |
| Type | Panel Mounted, DIN Rail Mounted |
